Specification:
Item name: iFlight CineBee 75HD 2S whoop
Total Dimensions: 110x93x30mm
Frame Wheelbase: 75mm
Bottom & Top Plate Thickness: 1mm
Standoff height: 22mm
Build Weight: 64.4g (without battery, receiver)
Connector: XT30
Support Battery: 2～3S
Flying Time: over 3mins (battery recommend: 2S 420 mAh)
SucceX Micro 16x16 F4 2-4S Flight Control
SucceX Micro 12A 4in1 2-4S BlheliS ESC
SucceX Micro 200mW switchable VTX
iFlight 1103 2-3S motors (1.5mm shaft)
Caddx.us Turtle v2 HD FPV Cam
Receiver: Without Receiver/ FS-A8S V2/ Frsky XM+/ Frsky R-XSR/ DSM2 DSMX Receiver (option)
Gemfan 1635 40mm 3-blade 1.5mm props
iFlight Prop Guards 40mm
Product Description
iFlight CineBee 75HD is the latest BNF creation of minimum weight at a spectacular performance, traditional but versatile and upgradeable design, carrying a 1080p (up to 60fps) micro cam stack and recording JELLOFREE footage flying through smallest gaps and spots. If slow cruising or fast racing, the cam angle goes from 0-55 degrees with motors from 2S-4S.
Our target was pretty clear, create a lightweight, durable but jellofree whoop that can shoot high-quality HD videos. We decided to use a combination of carbon, plastic, and TPU to have a rigid bottom plate that doesn't oscillate, with still crash resistant abilities and integrated prop guards giving the whole frame strength. The stack is soft-mounted, the cam is soft-mounted, the motors run smooth - keep your props in a good condition, and you won't have to worry about jello!
Features:
- Ultra-light but high performance
- JELLOFREE durable carbon/plastic construction
- No props or prop guards in view
- Upgradeable, versatile, futureproof
Specification:
- Total Dimensions: 110x93x30mm
- Frame Wheelbase: 75mm
- Build Weight: 66.2g
- SucceX Micro 16x16 Tower 2-4S
- iFlight 1103 motors (1.5mm shaft)
- Caddx.us Turtle v2 HD FPV cam
- Gemfan 1635 40mm 3/4 blade OR HQ 1.6x1.6x4
- iFlight Prop Guards 40mm
SucceX Mirco F4 Flight Tower System 16x16mm
SucceX F4 Flight Controller
-STM32F411
-Input voltage 2-4S LIPO
-Gyro: MPU6000
-2x UART ports
-4x motor outputs
-OSD inbuilt
-No Blackbox FLASH
-BEC 5V 2A cont.
-Size: 21mm*21mm
-Mounting holes: 16*16
-Weight: 2.5g
-BF target : MATEKF411
SucceX Mirco 12A Brushless ESC
-Firmware: BlheliS
-Input voltage : 2-4S LIPO
-Continuous current: 12A
-MCU: BB21F16G
-BEC : None
-ESC protocol: pwm, oneshot125, multishot, dshot150, 300, 600, etc.
-Size: 23mm*21mm
-Mounting hole 16*16mm
-Weight: 2.7g
SucceX Mirco VTX
-Power : PIT/25/100/200mW
-Antenna interface : IPEX (UFL)
-Telemetry: IRC Tramp
-Size: 17mm*27mm
-Mounting holes: 16*16mm
-Weight: 1.6g
Motor kV Variants:
-We offer several motor setups to fit your desired performance, equipment or just preference.
-(2S), (3S) will be available.
SD card insert and ejection:
-The HD cam PCB is conveniently placed under the frame, protected by a cover.
-To insert or eject the SD card, please push in the SD card and gently slide beside the security plastic guard.
VTX control implementation:
-VTX can be conveniently set up in your OSD.
Propeller recommendation:
-Gemfan for general use, durable prop, crash resistant!
-HQ for video recording, JELLOFREE, better throttle management, NOT crash resistant!
Receivers available currently:
-Frsky XM+
-Flysky FS-A8S
-Futaba FT4X
-SDMX RM601X
Optional:
-Frsky XM
-Frsky R-XSR
-Flysky IA8X
Package Included:
1 x CineBee 75HD
1 set Gemfan 40mm props
1 set HQ micro whoop props
Warm tips: Grasp bell before removing props to avoid damage.
