♦️スイス タグホイヤー キャリバーLWO283


ベース部分(時計部分)がETA 2892-2(2892A2ではない)

A2と2の違いは自動巻部の改良点だけ(?)

クロノグラフユニットがデュボアデプラ製Cal.2000

リンク先に同系統のムーブメントの紹介記事がありますので、詳細はOMEGA3220のページなどを参照ください。


自動巻 Automatic

振動数 28,800 vph

石数 40 Jewels

連続駆動時間 約42時間(H)

クロノグラフ

:センター 60秒計

:6時位置 12時間積算計

:9時位置 30分積算計

:12時位置 秒針

秒針停止機能 有り

日付

日付早送り機能 有り


テクニカルドキュメントより抜粋 読めないので転載

Characteristics

Wrist chronograph with two pushpieces placed at 32° either side of the crown.

Chronograph coupling by friction.

Combined hammer for hours-minutes-seconds tuned by eccentric.

Large centre seconds hand.

30 minute timer hand at 9 o'clock.

Hour minute timer at 6 o'clock.

Continuously running small second hand at 12 o'clock.

Stop-second device for when setting.

Rapid change date indicator at 3 o'clock.

Modular construction with chronograph module adaptable to two versions of existing calibres.



Cal. 283:

chronograph module: Dubois-Dépraz 2000

automatic cal.: ETA 2892-2


Chief dimensions

Case fitting diameter 29.30 mm

Total diameter 30.00 mm

Total height 6.50 mm

Height over stem 2.35 mm

Height over pushpieces 0.65 mm

Angle of pushpieces (total)64°

Bevel above yes

Bevel below (dial side) no

Fastening half-moon screw (2)


Performances (see specifications for ETA 11½''' automatic cal. ref. 2892-2)

Running time: mini: 40 hours


Jewelling

D + D 2000 module19

ETA 2892-2 21

Total 40
































以降の2892の部分についてはこちら
