Introduction
Described in one HP brochure as 'Unsurpassed in terms of software, expandability and versatility, these are the calculators that grow with your needs.' The HP41 series of calculators were considered by many people to be the ultimate calculator.They sold in massive numbers, had vast software support, spawned user groups like HPCC andwere even used on the Space Shuttle.
The HP-41C was launched in 1979 and was a quantum leap over previous programmable calculatorsdue to its alphanumeric capabilities and unique user interface. It had 63 registers which could be divided upbetween program space and storage space. Single memory modules adding blocks of 64 registerswere available allowing up to a maximum of 319 registers but doing so prevented the user addingROMs or peripherals. The 4 expansion slots could be utilised to drive a printer or acceptprinted programs from barcode or allow the addition of a magnetic card reader.
TRITON Le/Basic Guide. License Agreement. 1) All intellectual property contained in this library - including owner’s manuals and product literature - is the sole property of KORG Inc. Duplication of contents of owner’s manuals and/or product literature in part or in whole without the permission of the Company for the purposes of sharing. Korg triton le. This is the latest Operating System update for the TRITON Le. Primarily, It enhances the velocity scaling on the 76 model and fixes a file bug. A full listing of O.S. Changes in included as.pdf document in this download. The TRITON Le uses the SmartMedia slot to receive the O.S. Here is a demo of the Korg Triton Le Workstation. I am demonstrating mostly Synth Pads and Ambient sounds. KORG Triton LE 61 keys FOR SALE.
HP's first attempt at correcting this problem was the Quad memory module which allowed full expansionof user memory whilst using only 1 slot. A better solution came in the form of the HP-41CV whichhad the full 319 registers built in.
Crack de wilcom 2006 para windows 7 iso. The addition of the HP-IL interface loop allowed theaddition of printers, digital cassette drives, plotters, multimeters, modems,video interfaces and a host of other peripheralswhilst only occupying 1 slot. This left the other slots for ROM modules which could containprograms on virtually every (mathematically based) subject you could think of. Quake 3 arena macbook.
Perhaps the most interesting HP produced modules were the Time module and the Extended Functions module.Amongst other things the Time module allowed alarms to wake up the calculator and run programs allowing for example the system to becomea control unit in data collection applications using inputs from devices connected to the HP-IL system.The Extended Functions module provided a RAM disk system allowing program and data files to be storedand manipulated in extended memory (some of which was included in the module). HP supplemented thiswith additional Extended Memory modules providing additional non-volatile storage on the machine.
The HP-41CX then came out containing the capabilities of the HP-41CV plus the Time and Extended Functionsmodules plus some other unique features like a Text Editor for ASCII files in extended memory.
HP also ensured that the HP41 remained competitive against newer more mathematically powerful calculatorsby bringing out the Advantage Module which added some of the financial functions of the HP-12C, complex number and matrix handling like thoseon the HP-15C and computer science funtions like those of the HP-16C. When the next generation ofcalculators added Infrared printer support, HP brought out the 'Blinky' module.
Finally discontinued with the introduction of the HP48SX the HP41 series remains a testament to thepeople who developed it. A classic in its own lifetime.
Many more details of the HP41 series can be found in the HP Calculator Museum.
Principal Features
| HP-41CV |
Emulators
The HP41 series was so popular that emulators are available to run on the HP48 series, PCs and Pocket PCs.Look in the links section below or on www.hp41.org and www.hpcalc.org.
Availability
HP-41C Introduction-Discontinuation: 1979-85
HP-41CV Introduction-Discontinuation: 1980-1990
HP-41CX Introduction-Discontinuation: 1983-1990
Hp 41c Owners Manual Pdf
These machine are now quite sought after and consequently prices are reasonably high although bargains can sometimes be found on the comp.sys.hp48 newsgroup. HP-41 models are occassionally sold in the For Sale & Wanted column of Datafile and on eBay.
Books
Contact Wlodek to order books. HPCC members can find ordering details and a full book list in the Memberpack.
Extend Your HP-41by W.A.C. Mier-Jedrzejowicz
A very detailed book (sometimes called the HP-41 encyclopaedia!) about the HP-41 handheld calculator/computer, still popular in some applications. £20, postage in the UK & Europe £4. Few remaining.
Datafile Articles
| Title | Author | Datafile |
|---|---|---|
| EMU41 Update 2006 - HP41 to EMU41 on a PC via RS232 | Christoph Klug | V25N3P18 |
| HP41 to another HP41 via RS232 | Christoph Klug | V25N1P18 |
| HP41 and EMU41 Uploading ROM plug-in modules | Christoph Klug | V22N6P38 |
| HP-41 - PC Gateway & Emulator | Christoph Klug | V21N6P36 |
| Interfacing IL2000 System to Analogue World | Christoph Klug | V20N3P29 |
| IL2000 Interface System | Christoph Klug | V19N3P14 |
| HP-41 Hardware Interface Activities | Christoph Klug | V19N1P31 |
| HP-41 Input/Output-Board | Christoph Klug | V18N4P30 |
| Audio Measurement with HP-41 | Christoph Klug | V17N6P41 |
| Machine Code Debugger ROM, Quick Reference Guide and User GuideSource Code | Mark Power | V36N1P22 |
| HP-41 PLAY ROM | Mark Power | V36N4P31 |
Links
Hp 41c Battery
www.hp41.org
HP41 Quick Reference(from the Wayback Machine)
HP41 Programs and information(from the Wayback Machine)
HP41 Hardware Activities and Interfacing
HP41 HP-IL LIF File Utilities (for Linux)
HP41 Emulator (and other development tools/documentation)
HP41 Use on the Space Shuttle
HP-41C/CV/CX MicroCode Emulator (for HP48/49)
NEWT Microprocessor and 41CL Calculator Status Page (HP41 being rebuilt from scratch)
